Voigtländer Ultron 2/40 vs Konica Hexanon 1.8/40 on Sony A7R2
The lenses
Lens | Mount | Design | Aperture blades | min. Focus | Length | Weight | Filter |
---|---|---|---|---|---|---|---|
Konica Hexanon AR 40mm F1.8 | Konica AR | 6/5 | 6 straight | 0.45 m | 27 mm | 140 g | 55 mm |
Voigtländer Ultron 40mm F2 SL II | Nikon AI-P | 6/5 | 9 rounded | 0.25 m | 37.5 mm | 260 g | 52 mm |
As far as I know, there is only one version of the Hexanon.
There are two versions of the Ultron: The older one I'm testing here, and the newer SL II - S optimized for digital.
The lens designs are very similar: both are modified Planars, where the first negative group has been split into two. The Voigtländer has an aspheric rear element, and shows the typical onion rings in defocused highlights:
Konica | Voigtländer |
---|---|
Tests
All photos taken at ISO 100 using a tripod with EFCS on and a remote release. Developed in Capture One 11, no lens corrections applied, output sharpening disabled. These are 100% crops.
Scene 1 | Scene 2 | Scene 3 |
---|---|---|
Scene 1 near center (focus point)
Konica | Voigtländer | |
---|---|---|
f/1.8 f/2 |
||
f/2.8 | ||
f/4 | ||
f/5.6 | ||
f/8 | ||
f/11 |
Scene 1 edge
Konica | Voigtländer | |
---|---|---|
f/1.8 f/2 |
||
f/2.8 | ||
f/4 | ||
f/5.6 | ||
f/8 | ||
f/11 |
Scene 2 edge - Coma
The Voigtländer shows less coma, but also seems less sharp here. This is probably the result of greater field curvature, because in contrast to scene 1 I focused on the center.
Konica | Voigtländer | |
---|---|---|
f/1.8 f/2 |
||
f/2.8 | ||
f/4 |
Scene 3 - Sunstars
Photo taken at f/8.
Konica | Voigtländer | |
---|---|---|
Center | ||
Edge |
